Direct Methanol Fuel Cell

Independent Power Solutions for IoT and Mission Critical Installations. Maintaining battery charge when solar fails.
Direct methanol fuel cells are electrochemical power generators that use methanol. They emit only water vapour and small amount of carbon dioxide and no hazardous gases. They quietly generate pure direct current without EMI or mechanical wear unlike internal combustion generators. They are efficient and inexpensive to run and able to operate under harsh conditions – methanol only freezes below -97.8°

Key Features


Adjustable Voltage Range
All units have an adjustable on/off voltage range for both lead acid and LiFePO4 batteries

Efficient Fuel Consumption
Depending on actual running and environmental conditions, fuel consumption across all units is around 0.8~1.1L/kWh

Expandable Tank Sizes
The models customisable per voyage requirement and stacking is possible with interconnecting pipes.
Specification

DMFC-KH-50
- Max Power Output: 50W
- Output Power at 6000th hour: 35W
- Max. charging current @10.5V (12V battery pack): 3.3A
- Max. charging current @21.0V (24V battery pack): 1.7A
DMFC-KH-130R
- Max Power Output: 130W
- Output Power at 6000th hour: 91W
- Max. charging current @10.5V (12V battery pack): 12.4A
- Max. charging current @21.0V (24V battery pack): 6.2A
DMFC-KH-85
- Max Power Output: 85W
- Output Power at 6000th hour: 60W
- Max. charging current @10.5V (12V battery pack): 8.1A
- Max. charging current @21.0V (24V battery pack): 4A
DMFC-KH-200R
- Max Power Output: 200W
- Output Power at 6000th hour: 140W
- Max. charging current @21.0V (24V battery pack): 9.5A
